H Beam Assembling Machine

Product Description

H-Beam Assembling Machine

H-BEAM ASSEMBLING, WELDING AND STRAIGHTENING INTEGRAL MACHINE

This is special machine for H beam assembling, welding and straightening, it combines the three processes into one machine, thus improves productivity, reduces cost, and saves the installation space. It can produce H beam and T beam with high efficiency
Performance and characteristic

The main assembling machine adopts heavy duty assembling structure which has applied invention patent, web plate and flange plate centering and positioning automatically, to make the assembling precision and efficiency greatly improved.
Firm welding torch fix mechanism is set up separately, it not only can adjust height and horizontal moving position, also can adjust the angle of welding torch on two directions, it guarantees the nice seam form.
Assistant straightening machine has special designed structure, the two straightening rollers can straighten work piece automatically under the pushing of oil cylinder, straightening mechanism will not block the line of sight on seam, it is convenient to see the adjustment of welding torch and seam quality.
Assembling machine and assist straightening machine can be discharged and work separately.
Assistant straightening machine can work as small straightening machine after refit.

Standard Technical parameters of H-Beam Assembling Machine

Technical Parameter:

Web plate height	200 to 2000mm
Web plate thickness	6 to14mm
Straightening speed	0.35 to 3m/min
Flange plate width	200 to 800mm
Flange plate thickness	6 to 20mm
Main machine power	13.4kw

Advanced H Beam Assembly for Industry

This H Beam Assembling Machine is a cutting-edge solution for industrial manufacturing needs. It features a reliable touch screen for easy adjustments and monitoring, while its stainless steel alloy construction ensures long-lasting durability. The polished finish boosts corrosion resistance, making it a great choice for demanding environments. Operating on 240V bi-phase electricity, it supports automatic, high-efficiency workflows that are eco-friendly, reducing waste and energy consumption in your facility.


Effortless Operation and Maintenance

Designed with busy industrial facilities in mind, the machines automatic assembly process minimizes manual handling and accelerates production. Its intuitive touch screen allows for straightforward setup, quick diagnostics, and real-time status checks, even for users without specialized computer skills. Additionally, the warranty coverage ensures peace of mind for Indian manufacturers, wholesalers, and exporters who count on consistent performance.
